Special SLDDTM sound dynamic processing circuit. An inbuilt 0.5dB-0.8dB limiter delay, variable in delay value over frequencies.The channel gain is automatically reduced, protecting the loudspeakers from potential damage from the high power, continuous square waves that would otherwise be produced.
Perfect LXTM input overload limiter protection. The input works differently over varying frequencies and temperatures. This will ensure clean distortion-less sound.
Auto Ramp operates every time the amplifier is turned on or is reactivated after a protect condition is corrected. This exclusive NX-Audio feature gradually increases gain to the attenuator setting avoiding unnecessary stress on the loudspeakers.
LRSTM Short Circuit Protection : If an output is shorted (i.e., defective speakers or crossed speaker wires) the LRSTM will automatically Protect the amplifier. The LRSTM circuit senses the short circuit as an extremely stressful load condition and attenuates the signal, protecting the channel's output transistors from over-current stress.
Subsonic Frequencies : Built- in high pass filtering provides subsonic frequency protection for each channel.
XD7000 Key Features
XD7000 uses 2 oz thick pcb to handle powerful current amd thereby ensuring greater reliability and safety
XD7000 uses 12pcs of 100V/15000uF big capacitors to ensure higher headroom
XD7000 uses transformer with more headroom to ensure very high reliability. Even when the amplifier is under stress, very heavy load (for example at 2ohms) for long period of times, the amp is still very cool and as you are aware heat is the biggest killer for the amplifiers.
